Product Specs



Output Connector(s)
24-pin ATX Power	1
4+4-pin CPU power	2
6+2-pin PCIe power	2
SATA Power	4
Peripherals	4
CABLE SPECS
24-pin ATX power	600 mm, Nylon sleeving
4+4-pin CPU power	700 mm, Nylon sleeving
6+2-pin PCIe power	650 + 150 mm, Nylon sleeving
SATA power	500 + 150 mm
Peripherals	500 + 150 mm
AC INPUT RATING
100 – 240Vac	10A-5A 50Hz-60Hz
DC Output Rating
+3.3V	20A (120W)
+5V	20A (120W)
+12V	62.5A (750W)
-12V	0.3A (3.6W)
5Vsb	2.5A (12.5W)
Total	750W
Operation
PF Correction	Active @0.96
MTBF	100,000 hours
Operation Temperature	0 to 40°C
ENERGY EFFICIENCY
Rating	80 Plus Bronze
10% loading	86.2% @115Vac
20% loading	88.97% @115Vac
50% loading	88.7% @115Vac
100% loading	83.2% @115Vac
Fan Specs
Dimensions	120 x 120 x 25 mm
Speed	2400 ±10% RPM
Airflow	64.4 CFM (Tpy.)
Noise	39.92 dBA max
Bearing	FDB (Fluid Dynamic Bearing)
General
Dimensions (W x L x H)	150 x 140 x 86 mm
Material(s)	Steel, PCB and Plastic
Compliance Standard	ATX12V v2.53 / EPS12V v2.92
Regulation & Certification	FCC, Canada, CE, CB (IEC 62368-1), BIS, UKCA, CCC, BSMI, Mexico NOM
Hazardous Materials	Taiwan and China RoHS Table, CP65, EU REACH
Protections	OVP (Over Voltage Protection) UVP (Under Voltage Protection) SCP (Short Circuit Protection) OTP (Over Temperature Protection) OPP (Over Power Protection) OCP (Over Current Protection)
Warranty
Warranty	3 years
Model Number	PA-7B2BB / PS-2202





Reliable Power

DC-to-DC conversion ensures consistent power delivery to GPUs up to 220W, such as the RTX 3070.





Enhanced Safety

Tested for safety at up to 40°C, and features over-temperature and over-current protections.



Durable & Sleek

Main PSU cables are nylon-sleeved for durability with a matte black finish to match any build.
